316 Leica mojo3D, mojo3D Enhancements
Power:
•
The power supply for the multi section control kit must be able to supply 8 A
continuously from a permanent 12 V supply.
• If the Electric Steer Kit is also being used, the power supply must be able to
supply 13 A continuously at 12 V, and the multi section control kit must be
connected closest to the power source.
• A 5 m (16.4 ft) cable is supplied so that direct connection to the battery is
possible if required.

The Leica AS400 section controller should be located in any convenient place in the
vehicle cabin.
Software configu-
ration, step-by-
step 1. On the main navigation screen, tap the settings button.
2. On the flyout menu, tap the Vehicle Setup button.
3. Tap until the Section Controller / Implement mode screen is displayed.
4. Tap Leica AS400, to select it as the section controller.
