Leica mojo3D, mojo3D Enhancements 333
backing tape. Keep in mind that both GPS antennas should mount with the
whip antennas in the forward position.

Route the cables through existing grommets if possible; if not, modification
may be required to route the cables to the desired location. If creating a
new entry point, make sure to use a grommet to protect the cables.
2. Mount the red antenna in its previously marked out position, ensuring that it is
on the right–hand side of the vehicle when looking forward from the
operator's seat.
3. Mount the black (GeoPRO) antenna accordingly on the left-hand side.
