102 Leica mojo3D, Auto-Steer
5 Auto-Steer
5.1 Engage Auto-Steer
Auto-steer status The auto-steer button on the main navigation screen is used to engage and disen-
gage auto-steer. The colour of this button also indicates the current status of the
auto-steer.
• Red: Roading is active and auto-steer can not be engaged until
roading is turned off.
• Orange: Roading is turned off, but the conditions for auto-steer to
engage have not been met and auto-steer can not be engaged.
Stationary engage is not armed.
• Yellow: Roading is turned off and auto-steer is ready, but not
currently engaged. If the steering button is tapped the system will
auto-steer immediately because all engage criteria are currently
satisfied.
• Green with Pause: Auto-steer is armed but not active because the
vehicle is not moving or the engage criteria are not satisfied.
• Green: Auto-steer is engaged and the vehicle is being automati-
cally steered.
