24

Leica mojo3D, System Installation

The mojo3D is a 12-volt DC (negative-to-earth) system only.

Master input

The optional master input on the mojo3D power cable may be connected to an
external switch for remote operation of the Master Record Status button which
starts and stops coverage recording on screen.

The master input should be 12 V when on and ground or floating when off.
