4-25
4.4 Description of the units
4 Function Description
 7
– The safety system ends communication.
PLC Ready = 1/0 pulse edge
– Tool class PLC -> PSENvip Bit 1/2 = 0 or 1, depending on the orig-
inal status
INFORMATION
The requirements of the user program in the safety system are
described under "System Connections".
