11.1 Technical Details
11 Technical Details
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
11-2
The standards valid on 2010-03 apply.
SI_Kennzahlen_PSENvip
OSSD in accordance with EN 61496-1, type 4
Signal level at "0"
0 V DC (-3 V ... 2 V in accordance with EN 61496)
Signal level at "1" UB - 1 VDC (11 V ... 30 V in accordance with EN 61496)
Residual current at "0" signal Max. 1 mA (<2 mA in accordance with EN 61496)
Duration of on and off time during self test 40 µs
Max. cable resistance for detection of shorts between con-
tacts 16 Ohm
Max. capacitive load 20 nF for R
L
> 48 ohms with rated voltage
Max. inductive load 0.5 H
Overrun measurement
Signal level at "0"
0 VDC (-3 V ... 2 V)
Signal level at "1" UB - 1 VDC (11 V ... 30 V)
Residual current at "0" signal Max. 1 mA
Max. capacitive load 250 nF at 0 ... 500 mA
Transmitter synchronisation
Max. capacitive load
500 nF
Bending angle measurement
Measuring accuracy
+/- 0,25°
Angle range 50 ... 160°
Sheet metal thickness 2 mm … 4 mm
Temperature range 10 °C … 40 °C
Distance between metal sheet and receiver 0 m … 1.5 m
Min. blade length 20 mm
Environmental data
Protection type (EN 60529)
IP54
Ambient temperature 0 °C … 50 °C
(EN 60068-2-14)
Storage temperature
-35 °C … 70 °C
(EN 60068-2-1, EN 60068-2-2)
Climatic suitability
93 % rel. h. at 40 °C
(EN 60068-2-78)
Condensation
Not permitted
Vibration Frequency range: 10 Hz … 55 Hz
(EN 60068-2-6) Amplitude: 0.35 mm
20 cycles per axis
Shock
(EN 60068-2-29)
10 g, 16 ms
EMC EN 61000-6-4, EN 61496-1
Mechanical data
Dimensions (H x W x D)
Transmitter
115.5 mm x 112 mm x 168 mm
Receiver 115.5 mm x 112 mm x 228 mm
Weight
Transmitter
1700 g
Receiver 2900 g
Outputs on the receiver
