Preface MicroLogix 1000 Programmable Controllers User Manual
B–22
Mnemonic Instruction Type Name
Memory Usage
(user words)
True Execution
Time (approx.
µ
seconds)
False Execution
Time (approx.
µ
seconds)
HSD 7.00 8.00 1.25
High-Speed
Counter Interrupt
Disable
High-Speed
Counter
HSE 7.00 10.00 1.25
High-Speed
Counter Interrupt.
Enable
High-Speed
Counter
HSL 7.00 66.00 1.50
High-Speed
Counter Load High-Speed
Counter
IIM 6.78 35.72 1.50
Immediate Input
with Mask Program Flow
Control
INT 0.99 1.45 0.50
Interrupt
Subroutine Application
Specific
IOM 6.78 41.59 1.50
Immediate Output
with Mask Program Flow
Control
JMP 6.78 9.04 1.00 Jump to Label
Program Flow
Control
JSR 4.25 22.24 1.00
Jump to
Subroutine Program Flow
Control
LBL 0.99 1.45 0.50 Label
Program Flow
Control
LEQ 6.60 23.60 1.50
Less Than or
Equal
Comparison
LES 6.60 23.60 1.50 Less Than Comparison
LIM 7.69 36.93 1.50 Limit Test Comparison
LFL 33.67 61.13 1.50 LIFO Load Data Handling
LFU 35.08 64.20 1.50 LIFO Unload Data Handling
MCR 4.07 3.98 0.50
Master Control
Reset Program Flow
Control
MEQ 7.69 28.39 1.50
Masked
Comparison for
Equal
Comparison
MOV 6.78 25.05 1.50 Move Data Handling
