Preface MicroLogix 1000 Programmable Controllers User Manual
9–20
Exclusive Or (XOR)
The value at source A is Exclusive ORed bit by bit with the value at source B and
then stored in the destination.
Truth Table
Dest = A XOR B
A B Dest
0 0 0
1 0 1
0 1 1
1 1 0
Source A and B can either be a word address or a constant; however, both sources
cannot be a constant. The destination must be a word address.
Updates to Arithmetic Status Bits
With this Bit: The Controller:
S:0/0 Carry (C) always resets.
S:0/1 Overflow (V) always resets.
S:0/2 Zero (Z) sets if result is zero; otherwise resets
S:0/3 Sign (S)
sets if result is negative (most significant bit is set); otherwise
resets.
Execution Times
(
µ
sec) when:
True False
33.64 6.92
XOR
BITWISE EXCLUS OR
Source A
Source B
Dest
