Preface MicroLogix 1000 Programmable Controllers User Manual
6–10
Addressing Examples
•
T4:0/15 or T4:0/EN Enable bit
•
T4:0/14 or T4:0/TT Timer timing bit
•
T4:0/13 or T4:0/DN Done bit
•
T4:0.1 or T4:0.PRE Preset value of the timer
•
T4:0.2 or T4:0.ACC Accumulator value of the timer
•
T4:0.1/0 or T4:0.PRE/0 Bit 0 of the preset value
•
T4:0.2/0 or T4:0.ACC/0 Bit 0 of the accumulated value
