Using Math Instructions
8–5
Subtract (SUB)
Use the SUB instruction to subtract one value (Source B) from another (source A)
and place the result in the destination. Source A and B can either be a word address
or constant.
Updates to Arithmetic Status Bits
With this Bit: The Controller:
S:0/0 Carry (C) sets if borrow is generated; otherwise resets.
S:0/1 Overflow (V)
sets if underflow; otherwise reset. On underflow, the minor
error flag is also set. The value –32,768 or 32,767 is placed in
the destination. If S:2/14 (math overflow selection bit) is set,
then the unsigned, truncated overflow remains in the
destination.
S:0/2 Zero (Z) sets if result is zero; otherwise resets.
S:0/3 Sign (S) sets if result is negative; otherwise resets.
Programming
Execution Times
(
µ
sec) when:
True False
33.52 6.78
SUB
SUBTRACT
Source A
Source B
Dest
