Using Math Instructions
8–9
Divide (DIV)
Use the DIV instruction to divide one value (source A) by another (source B), and
place the rounded quotient in the destination. If the remainder is 0.5 or greater, the
destination is rounded up.
Updates to Arithmetic Status Bits
With this Bit: The Controller:
S:0/0 Carry (C) always resets.
S:0/1 Overflow (V)
sets if division by zero or overflow is detected; otherwise
resets. On overflow, the minor error flag is also set. The value
32,767 is placed in the destination. If S:2/14 (math overflow
selection bit) is set, then the unsigned, truncated overflow
remains in the destination.
S:0/2 Zero (Z)
sets if result is zero; otherwise resets; undefined if overflow is
set.
S:0/3 Sign (S)
sets if result is negative; otherwise resets; undefined if
overflow is set.
Changes to the Math Register
The unrounded quotient is placed in the most significant word, the remainder is
placed in the least significant word.
Programming
Execution Times
(
µ
sec) when:
True False
147.87 6.78
DIV
DIVIDE
Source A
Source B
Dest
