Industrial Connectors Han
®
Economic
and Reliable
Connections
Specifications
DIN EN 60 664-1 (VDE 0110-1)
Principles,
requirements and tests
DIN EN 61 984 (VDE 0627)
Connectors,
Safety requirements and tests
Note:
The connectors included in this ca-
talogue should not be coupled or de-
coupled under electrical load unless
otherwise stated.
The connector must not be powered-
up in the un-mated condition. This is
also true if the connector is closed
with a protection cover, unless other-
wise stated.
The provision of protection against
electric shock is the responsibility of
the user. Protection can be achieved
by the use of HARTING hoods and
housings coupled with/or alternatively
appropriate installation methods provi-
ded by the user.
The female connector in a HARTING
hood or housing offers finger safe pro-
tection according to relevant standards
for the mating face, even in the unma-
ted condition, unless otherwise stated.
Connectors of the same or different
series being mounted side by side
may be protected against incorrect
mating by the use of coding options.
Standard
DIN EN 175 301-801
Approvals
UL File No. E 23 50
CSA File No. LR 18 753, SEV
for inserts
GL certificate No. 13 674 - 99 HH
For "non standard applications" we can
manufacture designs to match your
requirements.
Please discuss requirements with us.
HARTING components help you
to construct top quality products
– economically and in line with market
requirements.
Certified according to EN ISO 9001
in design/development, production,
installation and servicing
Terminations
•
Screw terminal
•
Crimp terminal
•
Cage-clamp terminal
•
Wrap terminal
•
Solder terminal
•
Axial-screw terminal
•
Rapid terminal
•
IDC termination
Inserts
•
Leading protective ground
•
Polarised for correct mating
•
Interchangeability of male and female
inserts in hoods and housings
•
Captive fixing screws
•
Can be used with hoods and housings,
or for rack and panel applications
Hoods/Housings
•
Standard Hoods/Housings
•
Hoods/Housings for harsh environmen-
tal requirements
•
Hoods/Housings for intrinsically safe
plant
•
Degree of protection IP 65
•
Electrical connection with protective
ground
•
High mechanical strength and vibration-
resistance ensured by locking levers
•
Spring-loaded covers in shockproof
thermoplastic or metal covers, both
lockable
Accessories
•
Extensive range of cable protection
and sealing accessories
•
Protective covers available
•
Coding options for incorrect mating
protection
General information
It is the customer's responsibility to
check whether the components illus-
trated in this catalogue also comply
with different regulations from those
stated in special fields of applications.
We reserve the right to modify designs
or substance of content in order to im-
prove quality, keep pace with techno-
logical advancement or meet particu-
lar requirements in production.
No part of this catalogue may be reproduced in any form
(print, photocopy, microfilm or any other process) or pro-
cessed, duplicated or distributed by means of electronic
systems without the prior written consent of HARTING
Electric GmbH & Co. KG, Espelkamp. We are bound by
the German version only.
© HARTING Electric GmbH & Co. KG, Espelkamp – All rights reserved, including those of the translation.
