12.
03
Han-
Port
Han-Port ®
Technical
characteri-
stics
Technical characteristics
Frames
Material zinc die cast, smouthed surface
Suitable for wall thickness 1 … 5 mm
Dimensions outside (H x W x D) single: 114 x 66 x 32 ... 62 mm (depending on equipment)
double: 114 x 131 x 32 ... 62 mm (depending on equipment)
Operating temperature range -10 °C ... +60 °C
Stock temperature range -25 °C ... +60 °C
Degree of protection IP 65
Plug sockets Germany (VDE) USA / Euro USA (NEMA5-15)/ Japan France (UTE)
Nominal voltage, max. 250 V AC 250 V AC 125 V AC 250 V AC
Nominal frequency 50 Hz AC 60 Hz AC 50 Hz AC 50 Hz AC
Nominal current, max. 10 ... 16 A 15 A 15 A 10 ... 16 A
LED display Yellow 1) - - Yellow
Termination Screw terminal Screw terminal Screw terminal Screw terminal
Mounting depth assembled approx. 62 mm approx. 30 mm approx. 30 mm approx. 62 mm
Plug sockets Switzerland Great Britain (BS) Italy (CEI 23-16) Australia / China
Nominal voltage, max. 250 V AC 250 V AC 250 V AC 240 V AC
Nominal frequency 50 Hz AC 50/60 Hz AC 50 Hz AC 50/60 Hz AC
Nominal current, max. 10 A 13 A 10 ... 16 A 15 A
LED display - - - -
Termination Spring clamp terminal Screw terminal Screw terminal Screw terminal
Mounting depth assembled approx. 20 mm approx. 20 mm approx. 20 mm approx. 20 mm
Plug sockets Denmark India
Nominal voltage, max. 250 V AC 240 V AC
Nominal frequency 50 Hz AC 50 Hz AC
Nominal current, max. 13 A 13 A
LED display - -
Termination Spring clamp terminal Screw terminal
Mounting depth assembled approx. 20 mm approx. 17 mm
Data connectors D-Sub RJ45 USB
Nominal voltage, max. 125 V AC / 150 V DC 50 V AC/DC 30 V AC/DC
Nominal current, max. 3 A 1 A 1 A
Locking UNC 4-40 bolts stop bolt snap-in
Specification DIN 41 652 / IEC 807 Cat. 5e size A acc. to 2.0
Mounting depth assembled approx. 32 mm approx. 32 mm approx. 80 mm
Termination
Gender Changer Termination technology pluggable from both sides
1) Plug socket Yellow without LED display
