Han
Snap
Han-Snap ® Plastic housings
Features
• Ideal for use within closed electrical operation
enviroments
• Allows use off preassembled cables
• Optimised cost of material and assembly
• Insert can be assembled to Han-Snap ® element
with screwdriver
2 identical half shells form a shell housing.
Each housing has 3 cable entries, one on top and one at each
end. 2 x cable entries can be closed by enclosed blind plugs.
In the area of cable entries there are rectangular openings for
mounting of cable ties up to max. 5 mm width.
In the mating area both housing shells are fixed by the stan-
dard insert fixing screws.
To release the half shells use screw driver (3.5 x 0.5).
Alternatively, Han ® coding elements (code pins or guide pins
and bushings) may be used.
High mechanical security of the fixings.
No functional impairment is caused by slight over tightening of
the fixing screws. The blind plugs have slots for identification
strips.
The following labels can be fitted:
label 7 x 20 mm or
label 9 x 20 mm (more information page 11.17)
Technical characteristics
Range of delivery
Range of delivery comprises:
2 half shells with blind plugs
Min. retention force,
fixed 300 N
Vibration resistance IEC 60 068, part 2-6
BN 74018
Resistance to shock IEC 60 068, part 2-27
BN 74018
Tightening torque of fixing screws/
coding elements 0.8 Nm
Material Thermoplastic resin,
polycarbonate,
RAL 7032, grey
Flammability acc. to UL 94 V 0
Limiting temperatures -40 °C ... +125 °C
