Power
Distribution
Han-Power ® T with 3x Han-Modular ® Twin
Features
• 1 connection for power input and power output
each
• 1 T-connection to device
• 3 power contacts; 4 signal contacts
• Metal housing
• Locking lever Han-Easy Lock ®
Technical characteristics
Specifications DIN EN 61 984
DIN EN 60 664-1
Han-Power ® T
Number of contacts
- Power contacts 3
- Signal contacts 4
Electrical data
acc. to EN 61 984
Power side 40 A 400/690 V 6 kV 3
Rated current 40 A
Rated voltage conductor - ground 400 V
Rated voltage conductor - conductor 690 V
Rated impulse voltage 6 kV
Pollution degree 3
Signal side 16 A 400 V 6 kV 3
Rated current 16 A
Rated voltage 400 V
Rated impulse voltage 6 kV
Pollution degree 3
Rated voltage
acc. to UL/CSA 600 / V
Insulation resistance ≥ 10 10 Ω
Material zinc die-cast
Limiting temperatures -40 °C ... +125 °C
Flammability acc. to UL 94 V 0
Mechanical working life
- mating cycles ≥ 500
Degree of protection acc. to DIN EN 60 529 IP 65
Contacts
Han ® C module with Crimp terminal *
Number of contacts 3
Electrical data
acc. to EN 61 984 40 A 400/690 V 6 kV 3
Material polycarbonate
Insulation resistance ≥ 10 10 Ω
Temperature range -40 °C ... +125 °C
Flammability acc. to UL 94 V 0
Crimp terminal
- mm² 2.5 ... 6 mm²
- AWG 14 ... 10
Han ® EE module with Crimp terminal *
Number of contacts 8
Electrical data
acc. to EN 61 984 16 A 400 V 6 kV 3
Material polycarbonate
Insulation resistance ≥ 10 10 Ω
Temperature range -40 °C ... +125 °C
Flammability acc. to UL 94 V 0
Crimp terminal
- mm² 0.14 ... 2.5 mm²
- AWG 26 ... 14
* for more technical details see chapter 06
