Summary locking systems
Housing with 2 levers
Han-Easy Lock
®
❑ easy operation
❑ high degree of pressure tightness
❑ reliable locking guaranteed by 4 locking points
❑ space saving mounting
❑ ideal for mounting side by side
❑ cable to cable connection is possible
❑ high seal force
Details of Han-Easy Lock ® see chapter 31
Housing with 1 lever
Han-Easy Lock
®
❑ easily accessible, even with side entry
❑ possibility to lock protective covers on the housing
❑ cable to cable connection is possible
❑ 2 locking points on the longitudinal axis
1 lever in central position
❑ easily accessible, even with side entry
❑ 2 locking points on the lateral axis
❑ space saving mounting
❑ ideal for mounting side by side
❑ single hand operation
Screw locking / toggle locking
❑ hexagon nuts tightened with spanner
❑ highest degree of pressure tightness
❑ easily accessible, also with side entry
❑ use of tools avoids
access by unauthorized persons
Hood with 2 levers
Han-Easy Lock
®
❑ easy operation
❑ high degree of pressure tightness
❑ ideal for mating to housings with protection cover
❑ high seal force
Details of Han-Easy Lock ® see chapter 31
