05.

07

Han

Com

Han

®

K 4/4

Size 10 B

690/230 V 63/16 A

Identification

Part number

Drawing

Dimensions in mm

Stock items in bold type

Number of contacts

4/4 +

Part number

Identification

Male insert (M) Female insert (F)

Drawing

Dimensions in mm

Han

®

K 4/4

Axial screw terminal /

Cage clamp terminal

1) Distance for contact max. 21 mm

Contact arrangement view from termination side

finger safe

6 ... 16 mm²

"https://b2b.harting.com/ebusiness/en/

09 38 008 2601

"

"https://b2b.harting.com/ebusiness/en/

09 38 008 2701

"

finger safe

10 ... 22 mm²

"https://b2b.harting.com/ebusiness/en/

09 38 008 2602

"

"https://b2b.harting.com/ebusiness/en/

09 38 008 2702

"

not finger safe

6 ... 16 mm²

"https://b2b.harting.com/ebusiness/en/

09 38 008 2611

"

not finger safe

10 ... 22 mm²

"https://b2b.harting.com/ebusiness/en/

09 38 008 2612

"

Hex key SW 2.5

for axial setscrew

adapter 1/4“

"https://b2b.harting.com/ebusiness/en/

09 99 000 0375

"
