Tools
Tools
for
F.O. contacts
hinged frames
Identification Part number Drawing Dimensions in mm
Stock items in bold type 1) POF = Polymer optical fibre
Polishing tool
DIN 41 626
SC
POF 1) cable ∅ 2.2
Fibre stripper
0.3 mm
1 mm
0.18 / 0.3 mm
Crimping tool
for following 1 mm POF 1) contacts
Han D ® , Han E ®
DIN 41 626
Ferrule
F-SMA, -ST
HARTING crimping tool
for F.O. connector (glass fibre)
SW 4.3 mm
SW 3.8 mm
SW 4.95 mm
for crimping the strain relief to the connector
F.O. cable for glass fibre
HARTING crimping tool
for F.O. connector (plastic fibre)
SW 6.95 mm
SW 4.95 mm
SW 3.0 mm
for crimping the strain relief to the connector
F.O. cable for plastic fibre
Epoxy adhesive
glass fibre 2 ml EPO-TEK 360 with hardener (10:1), 4 g foil pack
