Han
Snap
Han-Snap ® Insert mounting with carrier element
Features
• Insert mounting with carrier element
• Suitable for all standard inserts size Han ® 6 B /
Han ® 10 B / Han ® 16 B / Han ® 24 B
• A practical solution to fix the insert directly on a
standard rail
• Insert can be assembled to Han-Snap ® element
with screwdriver
• Space saving
The carrier element is the basic element to mount the inserts
in the cross direction on standard rails, for example:
● Caprail, 35 x 7.5 or 35 x 15 acc. to DIN EN 60 715
● C-rail, C 30 acc. to DIN EN 60 715
● G-rail, G 32 acc. to DIN EN 60 715
Where vibration is likely to be encountered, use the 35 x 15
mounting rails. When using the large carrier element,
the 35 x 15 mounting rails are recommended to give greater
stability.
Insert mounting type 6/10 is suitable for inserts of sizes
Han 6 B and Han 10 B.
Insert mounting type 6/24 is suitable for all insert sizes:
Han 6 B / 10 B / 16 B / 24 B,
Han 16 A with the corresponding adapter.
Inserts can be assembled to the insert mountings with the
standard insert mounting screws.
High mechanical security of the fixings. No functional impair-
ment is caused by slight over tightening of the fixing screws.
Alternatively, Han coding elements (code pins or guide pins
and bushes) may be used.
The following labels may be fitted to the insert mounting parts
for circuit identification purposes:
- label 7 x 20 mm or
- label 9 x 20 mm (more information page 11.17)
Technical characteristics
Range of delivery
Range of delivery comprises:
2 insert mounting parts
1 carrier element
Min. retention force
on rail 450 N
Vibration resistance IEC 60 068, part 2-6
BN 74018
Resistance to shock IEC 60 068, part 2-27
BN 74018
Tightening torque of fixing screws/
coding elements 0.8 Nm
Material polycarbonate
Flammability acc. to UL 94 V 0
Limiting temperatures -40 °C ... +125 °C
