Han A
®
Technical characteristics
Stock items in bold type
Wire gauge
Part number
Identification
(mm²)
Male contact Female contact
Drawing
Dimensions in mm
Crimp contacts
silver plated
0,14-0,37
0,5
0,75
1
1,5
2,5
3
4
gold plated
0,14-0,37
0,5
0,75
1
1,5
2,5
4
Operating contact
Identification
Identifica-
tion
Wire gauge
Stripping
length
no groove
no groove
1 groove*
1 groove
2 grooves
3 grooves
wide groove
no groove
0,14-0,37
0,5
0,75
1
1,5
2,5
3
4
mm²
mm²
mm²
mm²
mm²
mm²
mm²
mm²
AWG 26-22
AWG 20
AWG 18
AWG 18
AWG 16
AWG 14
AWG 12
AWG 12
7,5 mm
7,5 mm
7,5 mm
7,5 mm
7,5 mm
7,5 mm
7,5 mm
7,5 mm
* on the back crimp collar
Current carrying capacity
The current carrying capacity of the connectors is limited by the thermal load capability of the contact element material including the
connections and the insulating parts. The derating curve is therefore valid for currents which flow constantly (non-intermittent) through
each contact element of the connector evenly, without exceeding the allowed maximum temperature.
Measuring and testing techniques according to DIN EN 60 512-5-2
Operating
current
Ambient temperature
Operating
current
Ambient temperature
Operating
current
Ambient temperature
➀ Wire gauge 2.5 mm²
➁ Wire gauge 1.5 mm²
➂ Wire gauge 1.0 mm²
