Hoods/Housings Han-Compact ®
Stock items in bold type
Identification Part number Drawing Dimensions in mm
Metal
Hoods
• side-entry
for Han-Compact ®
half gland
• with separate PE
termination
• for all inserts of size
Han-Compact ®
black
powder coated
black
chromated
Hoods
• side-entry
for Han-Compact ®
half gland
• for Han ® Q 8/0 Crimp,
Han ® Q 17/0 and
Han ® Q Data RJ45
black
powder coated
black
chromated
Hoods
• side-entry
for standard cable glands
• with separate PE
termination
• for all inserts of size
Han-Compact ®
black
powder coated
Hoods
• top-entry
for Han-Compact ®
half gland
• with separate PE
termination
• for all inserts of size
Han-Compact ®
black
powder coated
black
chromated
Hoods
• top-entry
for standard cable glands
• with separate PE
termination
• for all inserts of size
Han-Compact ®
black
powder coated
