Standard Hoods/Housings Han A ®
Size 3 A
Plastic hoods/housings for industrial applications / 1 lever locking system
Cable entry
Identification Part number metric Drawing Dimensions in mm
1) for metal housings and cable to cable hoods also
2) for mounted female insert or for mounted Han-Brid ®
insert
Stock items in bold type
Housings, surface mounting
side entry
light grey
black
Panel cut out 22 x 22 mm
Hoods, cable to cable
top entry
light grey
black
Protection covers
light grey
black
Protection covers for housings
light grey
black
Protection covers for hoods cable to cable
light grey
