Tools, Han e, For contacts – Northern Connectors Harting HAN Industrial Rectangular Connectors User Manual
Page 493

99.
05
Tools
Tools
for contacts
Han E
®
(09 33 ...)
Identification
Part number
Drawing
Dimensions in mm
Stock items in bold type
Insertion tool for crimp contacts
For crimp contacts with wires of less than 0.75 mm² it is re-
commended that an insertion tool is used. Contacts should be
inserted from the wiring side and pushed down until a positive
locking is achieved.
Insertion tool for Han
®
ES inserts
Removal tool for crimp contacts
for Han
®
EE, Han
®
Q 5/0, Han
®
Q 8/0,
Han E
®
, Han-Yellock
®
and Han A
®
A removal tool is necessary if contacts are to be replaced in the
insert. The tool is inserted from the wiring side until a stop is
noticeable. The wire with the crimp contact can then be pulled out
from the same side of the insert.
