Han
D / DD
02.
03
Han
®
8 D
Technical characteristics
Features
• High density of crimping contacts, up to 8 contacts /
connector
• Time saving rapid termination by use of crimping
contacts
• For requirements up to ∼ 50 V / — 120 V / 10 A
• Gold and silver contacts available
• Suitable for thermo- and 1 mm F.O. contacts
Specifications
DIN EN 60 664-1
DIN EN 61 984
DIN EN 175 301-801
Approvals
,
Inserts
Number of contacts
8
Electrical data
acc. to EN 61 984
10 A ~50 V / – 120 V 0.8 kV 3
Rated current
10 A
Rated voltage
~ 50 V
Rated voltage DC
– 120 V
Rated impulse voltage
0.8 kV
Pollution degree
3
Rated voltage
acc. to UL/CSA
50 V
Rated voltage
(direct voltage)
120 V
Insulation resistance
≥ 10
10
Ω
Material
polyamide
Limiting temperatures
-40 °C ... +125 °C
Flammability acc. to UL 94
HB
Mechanical working life
- mating cycles
≥ 500
Contacts
Material
copper alloy
Surface - hard-gold plated
2 µm Au over 3 µm Ni
Surface - hard-silver plated
3 µm Ag
Contact resistance
≤ 3 mΩ
Crimp terminal - min
0.14 mm² / AWG 26
Crimp terminal - max
2.5 mm² / AWG 14
Han-Quick Lock
®
- min
0.25 mm² / AWG 24
Han-Quick Lock
®
- max
1.5 mm² / AWG 16
Hoods/Housings Han
®
3 A
Thermoplastic
Material
polycarbonate
Surface
RAL 7032 (light grey)
RAL 9005 (black)
Locking element
lever, plastic
Flammability acc. to UL 94
V 0
Hoods/Housings seal
NBR
Limiting temperatures
-40 °C ... +125 °C
Degree of protection acc. to DIN EN 60 529
for coupled connector
IP 65 / IP 67
Metal
Material
zinc die-cast
Surface
powder coated
RAL 7037 (grey)
Locking element
lever, metal
Flammability acc. to UL 94
V 0
Hoods/Housings seal
NBR
Limiting temperatures
-40 °C ... +125 °C
Degree of protection acc. to DIN EN 60 529
for coupled connector
IP 44
IP 67 is achieved with seal
screw
Accessories
Crimping tools
chapter 99
Cable clamps
chapter 95
Coding of hoods/housings
chapter 95
Label acc. to CSA-approval
chapter 95
Han-Snap
®
chapter 11
Assembly plates for test connector chapter 95
