42.
03
Han
GND
Han ® GND
Features Technical characteristics
• New: First connector for potential equalization
• Slim, space saving design
• Low cost plastic hoods and housings
• Colours: green and yellow
• Separate axial screw contacts can be terminated
without any special tools directly to the wire.
Specifications
DIN EN 60 664-1
DIN EN 61 984
Hoods/Housings
Material
- hoods/housings polycarbonate
- seal NBR
- cable seal polyamide
Limiting temperatures -40 °C ... +85 °C
Flammability acc. to UL 94 V 0
Degree of protection
according to DIN EN 60 529
for coupled connectors IP 65
Mechanical working life ≥ 500 mating cycles
Cable diameter 7.5 - 14 mm
Modules
Number of contacts 1
Material polycarbonate
Limiting temperatures
-40 °C ... +125 °C
Flammability acc. to UL 94 V 0
Mechanical working life ≥ 500 mating cycles
Crimp Contacts
Material copper alloy
Surface
- hard-silver plated 3 µm Ag
Contact resistance ≤ 0.3 mΩ
Crimp terminal
- wire gauge 10 ... 35 mm²
Axial Screw Contacts
Material copper alloy
Surface
- hard-silver plated 3 µm Ag
Contact resistance ≤ 0.3 mΩ
Screw terminal
- wire gauge 1) 10 ... 35 mm²
- AWG 6 ... 2
- hexagonal driver SW 4
- tightening torque mm² 10 16 25 35
Nm 6 6 7 8
1) geometric wire gauge
