Han
Snap
Han-Snap ® Panel mounting
(Thermoplastic)
Features
• Snap element for sheet-metal cut out
• practical and easy handling
• Reduction of material and assembly costs
• For all standard Han ® B inserts and terminal block
connectors
• Space saving
Connector inserts and terminal block connectors can be fixed
on elements for panel mounting with standard insert mounting
screws.
High mechanical security of the fixings. No functional impair-
ment is caused by slight over tightening of the fixing screws.
Alternatively, Han coding elements (code pins or guide pins
and bushes) may be used.
Connector assembly into the panel (sheet-metal) cut out or two
parallel mounted rails is possible from mating or termination
side.
Technical characteristics
Range of delivery
Range of delivery comprises:
2 panel plastic mounting parts sufficient for
one insert or terminal block connector
Min. retention force in sheet-metal cut out
- Mating
without guiding 250 N
with guiding 400 N
- Unmating
without guiding 400 N
with guiding 500 N
Vibration resistance IEC 60 068, part 2-6
BN 74018
Resistance to shock IEC 60 068, part 2-27
BN 74018
Tightening torque of fixing screws/
coding elements 0.8 Nm
Material Thermoplastic resin,
polycarbonate,
RAL 7032, grey
Flammability acc. to UL 94 V 0
Limiting temperatures -40 °C ... +125 °C
