Han
®
Q 7/0
Size 3 A
400 V 10 A
Stock items in bold type
Number of contacts
7 +
Part number
Identification
Male insert (M) Female insert (F)
Drawing
Dimensions in mm
Crimp terminal
Order crimp contacts
separately
Contact arrangement view from termination side
Coding pins
Wire gauge
Part number
Identification
(mm²)
Male contact Female contact
Drawing
Dimensions in mm
Crimp contacts
Power contacts
Wire gauge
Stripping length
0.14-0.37
0.5
0.75
1
1.5
2.5
0.9
1.1
1.3
1.45
1.75
2.25
silver plated
0.14-0.37
0.5
0.75
1
1.5
2.5
gold plated
0.14-0.37
0.5
0.75
1
1.5
2.5
F.O. contacts
for 1 mm plastic fibre
