Han-Brid ® USB / Han-Brid ® FireWire
Han-Brid ® USB Han-Brid ® FireWire
Features
• Insert for all Han ® 3 A hoods and housings
• Hood with glued sealing
• Simple and low-cost termination via insert of a
patch cable
• Strain-relief via cable tie
Technical characteristics
USB style A, 2.0 Standard
Specifications DIN EN 60 664-1
DIN EN 61 984
Number of contacts 4
Electrical data
acc. to EN 61 984 1 A 50 V 0.8 kV 3
Rated current 1 A
Rated voltage 50 V
Rated impulse voltage 0.8 kV
Pollution degree 3
Material polycarbonate
Insulation resistance ≥ 10 10 Ω
Contact resistance ≥ 4 mΩ
Temperature range -40 °C ... +85 °C
Flammability acc. to UL 94 V 0
Mechanical working life
- mating cycles ≥ 500
Features
• Insert for all Han ® 3 A hoods and housings
• Hood with glued sealing
• Simple and low-cost termination via insert of a
patch cable
• Strain-relief via cable tie
• Compatible to IEEE 1394
Technical characteristics
Firewire IEEE 1394
Specifications DIN EN 60 664-1
DIN EN 61 984
Number of contacts 6
Electrical data
acc. to EN 61 984 1 A 50 V 0.8 kV 3
Rated current 1 A
Rated voltage 50 V
Rated impulse voltage 0.8 kV
Pollution degree 3
Material polycarbonate
Insulation resistance ≥ 10 10 Ω
Contact resistance ≥ 4 mΩ
Temperature range -40 °C ... +85 °C
Flammability acc. to UL 94 V 0
Mechanical working life
- mating cycles ≥ 500
