59
S
ETUP
F
IELD
O
PERATIONS
2. If you chose to create an Inner Boundary, use the Region Type drop-down menu to choose the type
of boundary. Choices include: Roadway, Body of Water, Waterway, Buildings or Undefined.
3. The Boundary Offset feature enables mapping a boundary at a user-defined distance to the left or right
of the GPS antenna center line. If desired, specify a Boundary Offset distance by choosing a direction and
distance from the GPS antenna center line.
4. Press to start the boundary.
5. During the creation of a boundary, the Pause/Resume button and Stop button
appear at the top of the Field tab.
6. Press the Stop button to complete the boundary. At the Boundary screen, choose
whether to Save, Resume or Discard the boundary.
Pause Boundary
When creating a boundary, you can use the Pause Boundary button to create a
straight line between two points. To do this, drive the vehicle to a point, press the
Pause Boundary button, then drive to the second point. When you press the
Resume Boundary button, a straight line is created between your current point and
your pause location.
H
EADLANDS
Press the Headlands button on the Field tab to access the Headland Options
screen.
A Field Boundary is required to create a headland.
Enable Headlands - use checkbox to turn
Headlands functionality on and off
Add Headland
Load a Headland
Edit Headland
Alarm Settings
Field
Headlands
Topography
Boundary
Field
Headlands
Topography
Enable Headlands
Headlands Options
Active Area
All
