139

UIDANCE

RAC

The Control Point of a vehicle is defined as:

• Standard Wheeled Vehicle (MFWD, Floater, Sprayer) - Rear Axle

• Track Vehicle - Center of tracks

• Articulated Tractor - Pivot point of vehicle

• Combine/Swather - Front Axle

Press .

8. Enter Antenna Lateral Offset. Select Left or Right. Press

Note:

The Antenna Lateral Offset value is tested and adjusted (if necessary) after vehicle creation

and calibration is complete. Use left or right buttons to indicate if antenna is left or right of the
vehicle’s center. If the antenna is perfectly centered, it does not matter which button is pressed as

long as the measurement is zero.

9. Enter Antenna Height, and then press the checkmark button.

The Wizard now takes you to the Manual Steering Override kickout limit setting procedure. When the
Manual Steering Override calibration is complete, the Setup Wizard starts the Auto Calibrate procedure.

ANAGE

EHICLE

Press: Vehicle button > Manage Vehicle button

The Manage Vehicle screen enables you to:

select the active vehicle

change vehicle parameters

delete vehicle

import and export vehicle profiles

ELECT

Select Vehicle

Press: Vehicle button > Manage Vehicle button > Select Vehicle > Select button

To make a vehicle profile the Active Vehicle, select vehicle from list and press the Select button. The
confirmation box will appear. Press the checkmark button and then Back icon to return to the AutoSteer
Setup menu.

Vehicle

Manage
Vehicle

Select

Edit

Delete

Export/
Import

Vehicle

Manage
Vehicle

Select
