236 Firmware Version 5.2
2. Make sure the Outside Boundary Option is set to Turn Section Off under the Automatic Swath
Control options.
3. Make sure there is not a gap between the boundary and the first pass of the headlands.
Note: For best results, run a new boundary when spraying the first pass of the headlands.
Problem: Booms turn on briefly (less than a second) in the headlands
Solution:
1. Make sure that the turn on look-ahead is greater than the turn off look-ahead.
2. Make sure GPS offsets are correct.
3. Make sure look aheads are less than three seconds each.
J
OHN
D
EERE
S
PECIFIC
I
NSTRUCTIONS
Here are some tips to remember when operating the display in conjunction with a SprayStar
1
control
system. Refer to the quick reference sheet and other sections of the operators manual for specific setup
and operation instructions.
Master Switch Input
After setting up a configuration in the display make sure to change the master switch input setting from
standard to optional. This will tell the display to read the foot pedal for the master switch input status.
Master Switch Usage
When manually shutting off all boom sections in the field, use the foot pedal switch. Leave the OEM
master switch on the hydro handle ON during field use. Using the hydro handle switch may lead to
improper field coverage, poor AutoSwath performance, and inaccurate spray records. Only use the John
Deere master switch when completely shutting down the sprayer to transport or service the machine.
Target Rate
The display must have a non-zero target rate entered in the display before the boom valves will open for
product application. Ensure that the target rate entered into the display and SprayStar match to avoid
any unwarranted alarms or warnings on the display.
Data Collection
The display will create a coverage map of all product application while logging actual application rate
from the product control system flow meter.
AutoSwath Boom Section Control
The display will automatically control the boom section on/off status based upon previously applied area,
field boundary, and internal boundaries.
SprayStar Application Rate
The display will not control the rate based upon the target rate value entered into the system.
Application rate is controlled exclusively by the SprayStar display.
1. SprayStar is a trademark of Deere & Company.
