ITEM PART NO. QTY. DESCRIPTION
1 GA17432 1 See “Electric Compressor” on page P97
2 GA17575 1 See “Air Tank Assembly” on page P99
3 GA17631 12 See “Pneumatic Down Pressure Row Unit Assembly” on page P7
4 GD17150-02
GD17150-03
GD17150-09 1
-
-
Nylon Tubing, ⅜" O.D. x 44', 12 Row
Nylon Tubing, ⅜" O.D. x 64', 16 Row
Nylon Tubing, ⅜" O.D. x 82', 24 Row
5 GD17151-15
GD17151-02
GD17151-12 1
-
-
Nylon Tubing, ¼" O.D. x 60', 12 Row
Nylon Tubing, ¼" O.D. x 70', 16 Row
Nylon Tubing, 1/4" O.D. x 112', 24 Row
6 GD18796 2 Reducer, ⅜" To ¼"
7 GD19080 12 Elbow, ¼" x ⅛" NPT Swivel
8 GD26110 10 Reducing Tee, ⅜" x ¼" x ⅜"
9 GD1114
GD25914 2
-
U-Bolt, 7" x 7" x ⅝"-11, 12 Row and 16 Row
U-Bolt, 7" x 3" x ⅝"-11, 24 Row
10 G11415 4 Serrated Flange Nut, ⅝"-11
11 --- - ---
12 GA19404 1 Basic PDP Cable
13 GA18265
GA18264
GA18263 1
-
-
12V Air Pump Harness, 12 Row
12V Air Pump Harness, 16 Row
12V Air Pump Harness, 24 Row
14 --- - ---
15 GA19422 1 Row Module Breakout Cable
16 GD18010 - Tee, ⅜" Tube Union
Pneumatic Down Pressure Option
TM
M0247-02 Model 4900
P95 Rev. 2/14
