Drawbar Hitch Assembly
ITEM PART NO. QTY. DESCRIPTION
1 GA14174 1 Inner Hitch
2 GA17588 1 Outer Hitch
3 GA9526 1 Swivel Block
4 GA9856 1 Safety Chain, ⅝"
5 GA14184 1 See “Drawbar Hitch Cylinder” on page P131
6 GA19428 2 S/A HYD BLOCK
7 GA18129 1 Jack Stand
8 GA18130 2 Safety Pin
9 GB0230 6 Cap
10 GB0234 6 Adjustment Plug
11 GB0361 1 Single Clevis, Swivel Hitch
12 GD3421 2 Pin, 1¼" x 8¾"
13 GD9093 6 Poly Wear Pad
14 GD13377 1 Spindle
15 GD20102 4 Shim, 1½" x 5", 7 Gauge (.1793") (As Required)
16 GD20188 2 Wear Pad
17 GD20190 8 Shim, 1½" x 5", 10 Gauge (.1345") (As Required)
18 GD20191 4 Shim, 1½" x 5", 14 Gauge (.0747") (As Required)
19 GD20229 1 Outer Plate Cover
20 GD21307 1 Washer, 3¾"
21 GD25694 2 Wear Plate
22 G10620 2 Serrated Flange Nut, 5/16"-18
23 G10936 2 Hex Head Cap Screw, 5/16"-18 x 3½"
24 G6801-LLL-08 1 X-Long Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
25 G6400-08
GR1037 1
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
26 G6500-08 1 Swivel Elbow, 90°, ¾"-16 Male JIC To Female
27 G10004 3 Hex Head Cap Screw, ⅜"-16 x 1¼"
28 G10006 8 Hex Head Cap Screw, ⅝"-11 x 2¼"
29 G10014 12 Hex Head Cap Screw, ½"-13 x 1"
30 G11387 3 Flat Washer, ⅜" SAE
31 G11186 1 Hex Head Cap Screw, 1"-8 x 6½", Grade 5
32 G10042 2 Hex Head Cap Screw, 1¼"-7 x 6½"
33 G10494 1 Hex Head Cap Screw, 1¼"-7 x 3½"
34 G10157 3 Lock Nut, 1¼"-7
35 G10460 4 Cotter Pin, ¼" x 2"
36 G10230 8 Lock Washer, ⅝"
37 G10396 1 Lock Nut, 1"-8
Model 4900 M0247-02
Rev. 2/14 P68
