Kinze 4900 Front Folding Planter Rev. 3/14 User Manual
Page 13
ITEM
PART NO.
QTY.
(Per Row)
DESCRIPTION
1
GD11001
1
Spindle
2
G10940
16
Machine Bushing, 1" (.048" Thick)
3
GD10991
4
Seal
4
GB0276
4
Bushing, 1" I.D. x 1¼" O.D. x 1" Long
5
GB7975
GB7976
1
1
L.H. Gauge Wheel Arm (Shown)
R.H. Gauge Wheel Arm
6
G10640
2
Grease Fitting, ¼"-28
7
G10204
2
Special Machine Bushing, ⅝" x 1" O.D.
8
G10010
2
Hex Head Cap Screw, ⅝"-11 x 3"
9
G10230
2
Lock Washer, ⅝"
10
GB0655
2
Gauge Wheel Cover
11
GD26099
4
Half Gauge Wheel
12
GD1086
2
Tire
13
GA6171
2
Bearing
14
G10924
8
Carriage Bolt, 5/16"-18 x 1¾"
15
G10620
20
Serrated Flange Nut, 5/16"-18
16
G10018
14
Hex Head Cap Screw, 5/16"-18 x ⅝"
17
G10109
14
Lock Nut, 5/16"-18, Grade 8
18
G10338
12
Carriage Bolt, 5/16"-18 x 1¼"
19
G10216
2
Washer, ½" USS
20
G10228
2
Lock Washer, ½"
21
G10014
2
Hex Head Cap Screw, ½"-13 x 1"
22
G10037
1
Hex Head Cap Screw, ½"-13 x 1¼"
A
GA16333
-
Gauge Wheel Complete (Items 10-18)
Gauge Wheels
Model 4900
M0247-02
Rev. 2/14
P10
