Coulter Mounted Residue Wheels
ITEM
PART NO.
QTY.
(Per Row)
DESCRIPTION
1
GB0464
1
Residue Wheel Mount
2
GD26973
1
Cam Locking Pin
3
G10229
2
Lock Washer, ⅜"
4
G10004
2
Hex Head Cap Screw, ⅜"-16 x 1¼"
5
GA14251
1
Cam
6
GD10519
1
Spring
7
G11389
1
Flat Washer, ½" Plated SAE
8
GB0383
2
Bushing, 1⅛" O.D. x 25/32" I.D. x ¾" Long
9
G11392
2
Flat Washer, ¾" SAE
10
G10026
2
Hex Head Cap Screw, ¾"-10 x 2"
11
GA8760
G10765
2
-
Weed Guard W/Spring Pin
Spring Pin, ¼" x 1"
12
G10213
4
Machine Bushing, ⅝" (.030" Thick)
13
GB0387
2
Wheel, 12 Tine, ⅜" x 12"
14
GA5654
GA2014
2
-
Hub W/Bearings
Bearing
15
GD9724
2
Backing Plate
16
G10133
12
Hex Head Cap Screw, 5/16"-18 x 1½"
17
G10109
12
Lock Nut, 5/16"-18, Grade 8
18
G10974
1
Lock Nut W/Nylon Insert, ½"-13
19
G10010
2
Hex Head Cap Screw, ⅝"-11 x 3"
20
G10503
2
Hex Jam Nut, ⅝"-11, Grade 2
21
GD1132
2
Dust Cap
A
GA12235
-
L.H. Residue Wheel (Items 13-17)
B
GA12236
-
R.H. Residue Wheel (Items 13-17)
Model 4900
M0247-02
Rev. 11/13
P22
