Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 220)

Piston Pump with Flow Dividers, 24 Row Bulkfill
ITEM PART NO. QTY. DESCRIPTION
1 G10279 1 1" Female NPT Nylon Tee
2 G10624 1 1" Male NPT x 1¼" Hose Barb
3 G10101 8 Hex Nut, ⅜"-16
4 G11387 10 Flat Washer, ⅜" SAE
5 GD26274 1 U-Bolt, 1½" x ¼"-20
6 G10110 6 Lock Nut, ¼"-20, Grade B
7 G10674 6 Hose Clamp, No. 24
8 G10681 48 Hose Clamp, No. 6
9 GD11700 48 Adapter, ¼" NPT To ⅜" Barb
10 GA8931 2 See "Liquid Fertilizer Piston Pump Flow Divider" on page P241
11 GD13348 24 Insulated Clamp, 11/16"
12 G4301-08 2 Hose, ⅜" x 250'
13 GA18345 4 Hose Support
14 G10308 8 Carriage Bolt, ⅜"-16 x ¾"
15 GA18590 1 Fertilizer Tee Mount
16 GD11721 2 U-Bolt, 5" x 7" x ½"-13
17 G10228 4 Lock Washer, ½"
18 G10102 4 Hex Nut, ½"-13
19 G11458 1 Adapter 1" Flange x 1¼" Hose Barb
20 G11498 1 Gasket, Flange Ribbed 1"
21 G11467 1 Flange Clamp SS 50 Series
22 G11091 4 Serrated Flange Nut, ⅜"-16
23 --- 2 See "Center Ground Drive Assembly" on page P226
24 GA18875 2 Piston Pump Mount
25 G10001 4 Hex Head Cap Screw, ⅜"-16 x 1"
26 G10014 4 Hex Head Cap Screw, ½"-13 x 1"
27 G10071 12 Serrated Flange Nut, ½"-13
28 GD15532 2 Bronze Bushing, ⅜" x ½"
29 GA11287 2 Double Idler Assembly
30 G10108 4 Lock Nut, ⅜"-16
31 G10306 2 Carriage Bolt, ⅜"-16 x 2"
32 G10552 2 Clevis Pin, ⅜" x 2"
33 G10860 4 Retaining Ring, ⅜"
34 GD5857 2 Spring
35 G3310-82
GR0912 2
-
Chain, No. 40, 82 Pitch Including Connector Link
Connector Link, No. 40
36 G10017 8 Hex Head Cap Screw, ½"-13 x 1½"
37 G10870 2 Clevis Pin, ⅜" x 1"
38 GA12330 2 See "Liquid Fertilizer Piston Pump (Uses 18 Tooth Sprocket)" on page P239
39 G11561 2 90° Elbow, 1½" Male NPT x 1¼" Hose Barb
40 G11237 2 Reducing Bushing, 1½" Male NPT To ¾" Female
41 G10917 4 Elbow, 90°, ¾" NPT To Barb
42 GA18466 2 Flow Divider Mount
43 GD25914 2 U-Bolt, 7" x 3" x ⅝"-11
44 G10104 4 Hex Nut, ⅝"-11
45 G10230 4 Lock Washer, ⅝"
46 G11083 2 Coupler, ¾" Female NPT
47 G11460 2 90° Elbow, 1" NPT x 1¼" Hose Barb
48 G10278 4 Hose Clamp, No. 16
49 G4200-01 1 Hose, 1¼" x 22'
50 G4205-18 1 Hose, ¾" x 744"
51 GD26672 2 U-Bolt, 2" Diameter, ¼"-20
52 G11385 6 Flat Washer, ¼" SAE
53 --- 2 See "Liquid Fertilizer Piston Pump (Uses 18 Tooth Sprocket)" on page P239
54 G11389 2 Flat Washer, ½" Plated SAE
55 G10004 2 Hex Head Cap Screw, ⅜"-16 x 1¼"
TM
M0247-02 Model 4900
P217 Rev. 11/13
