Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 101)

Electric Compressor
ITEM PART NO. QTY. DESCRIPTION
1 GA17623 1 12V Electric Compressor Mount
2 --- - ---
3 GB0766 1 Compressor Cover
4 GA14127
GR1943 1
-
Filter Assembly
Filter Element Replacement
5 G10110 2 Lock Nut, ¼"-20, Grade B
6 G10638 2 Hex Head Cap Screw, ¼"-20 x 2"
7 G11382 4 Washer, No. 10 SAE
8 G11385 2 Flat Washer, ¼" SAE
9 G11356 2 Hex Socket Flange Cap Screw, ¼"-20 x ½"
10 G10949 4 Hex Nut, #6-32, Grade 1
11 G11206 4 Lock Nut, No. 10-32
12 G10950 4 Slotted Phillips Head Machine Screw, 6-32 x ½", Grade 1
13 G10904 4 Slotted Phillips Head Machine Screw, 10-32 x 1", Grade 1
14 GA18212 1 12V Air Pump W/Connector
15 GA18001 1 Compressor Mount
16 G10002 4 Hex Head Cap Screw, ⅜"-16 x ¾"
17 G11387 4 Flat Washer, ⅜" SAE
18 G10622 4 Serrated Flange Nut, ⅜"-16
19 GA18482 1 Air Compressor Harness
20 GR1921 - Check Valve
21 GR1951 - Leader Hose without Check Valve
22 GD17141 1 Connector, ¼" Male NPT
23 GD25486 1 Manifold Block
24 GD26387 1 Plug, ⅜" NPT
25 GD26386 1 Plug, ⅛" NPT
26 GD26070 2 Plug, ¼" NPT
27 GA18211
GD26069 1
-
Air Pump Pressure Switch W/Connector
Pressure Switch
A GA17994 - Compressor Manifold (Items 22-27)
Model 4900 M0247-02
Rev. 11/13 P98
