Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 147)

ITEM PART NO. QTY. DESCRIPTION
1 GA17352 1 Barrel (Non-Stock Item)
2 GA16081 1 Check Valve
3 GA17356 1 ⅜ " Hydraulic Steel Tube
4 *D12239 2 O-Ring, No. 016
5 G6400-06
GR1045 1
-
Connector W/O-Ring, 9/16"-18 Male JIC To O-Ring
O-Ring
6 G6408-08
GR1037 2
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
7 GD25264 2 Manifold Block
8 G10932 4 Hex Socket Head Cap Screw, 5/16"-18 x 2", Grade 8
9 *D12030 2 Piston Ring
10 *D12220 1 Energizer Seal
11 *D12032 1 Piston Seal
12 GD11994 1 Piston
13 *D12208 1 O-Ring, No. 214
14 *D12216 1 O-Ring, No. 344
15 *D12219 1 BU Ring
16 *D12253 1 U-Cup
17 GD11995 1 Gland
18 *D12200 1 Wiper, 1¾"
19 GD12104 1 Ring
20 GA17354 1 Rod
21 G10640 1 Grease Fitting, ¼"-28
22 GD27235 1 Nylon Lock Nut, 1"-14, Grade 8
23 G6408-06
GR1045 3
-
Plug W/O-Ring, 9/16"-18 O-Ring
O-Ring
A GA17351 - Hydraulic Cylinder Complete, 4¼" x 9¼" (Part Number Stamped on Barrel)
B GR2115 - Seal Kit, Includes: (1)Piston Ring, (1)Piston Seal, (1)Energizer Seal, (3)O-Ring, (1)
BU Ring, (1)Wiper, (1)U-Cup
C GR1517 - Seal Kit For Counter Balance Valve, Includes: (3) O-Rings, (3) BU Rings
*Item is part of seal kit, item can not be purchased individaully.
Slave Cylinder, 24 Row (With Flip Axle)
Model 4900 M0247-02
Rev. 11/13 P144
