ITEM PART NO. QTY. DESCRIPTION
1 *A1054 - Hose Assembly, ⅜" x 204"
2 *A15020 - Hose Assembly, ⅜" x 38"
3 *A15035-377 - Hose Assembly, ⅜" x 377" (06F-08F)
4 *A18630-384 - Hose Assembly, ½" x 384" (08F-08F)
5 *A11482-377 - Hose Assembly, ⅝" x 377" (10F-12F)
6 *A11469
GA15499 -
- Hose Assembly, ⅝" x 98" w/Tip
Coupler
7 *A12787
GD4086 -
- Hose Assembly, ½" x 98" w/Tip
ISO Coupler
8 *A11482-384 - Hose Assembly, ⅝" x 384" (10F-12F)
9 *A18630-384 - Hose Assembly, ½" x 384" (08F-08F)
10 *A15035-384 - Hose Assembly, ⅜" x 384" (06F-08F)
11 *A1057 - Hose Assembly, ⅜" x 216"
12 *A12742 - Hose Assembly, ½" x 216"
13 G2700-08
G306-08 2
2 Bulkhead Tube Union, ¾"-16 Male JIC
Lock Nut, ¾"-16
14 G2700-12
G306-12 2
2 Bulkhead Tube Union, 11/16"-12 Male JIC
Lock Nut, 11/16"-12
15 GD25522 - Hydraulic Tip Cover
16 GA15499 - Coupler (Used W/Item No. 6)
* Hydraulic hose is not stocked by Kinze Repair Parts, but can be made available on a special order basis. Call for
quote.
Vacuum and Bulkfill Hydraulic Schematic, 24 Row
Model 4900 M0247-02
Rev. 11/13 P126
