Liquid Fertilizer Tank Hoses and Fittings,
16 Row and 24 Row with Bulkfill
ITEM PART NO. QTY. DESCRIPTION
1 GA18788
GA18791 1
-
300 Gallon Tank Mount, 16 Row
500 Gallon Tank Mount, 24 Row
2 GA17900
GA17899
GA16428
GA16157
GR2056
GR1709
GR1941
GR2144
GR1919
GR1739 1
-
1
-
-
1
1
1
2
2
Tank W/Lid and Fittings, 300 Gallon, 16 Row
Tank W/Lid and Fittings, 500 Gallon, 24 Row
7" Lid Assembly
Vacuum Breaker
7" Lid W/2" NPT
1¼" Bulkhead Fitting Assembly (Nut, Bushing And O-Ring) (End Of Tank)
Seal
½
" Bulkhead Fitting
1½" Bulkhead Fitting Assembly, 16 Row Only
2" Bulkhead Fitting Assembly (Nut, Bushing And O-Ring) (Bottom Of Tank), 24 Row Only
3 GA2660 1 Shutoff Valve, 2" NPT
4 GA18180 1 3-Way Flanged Ball Valve, 2"
5 GA18181 1 1" Manifold T Strainer W/30 Mesh Screen
6 GA18182 1 1" Manifold T Strainer W/80 Mesh Screen
7 GA18468
GA18467 1
-
Hose Guide, 16 Row
Hose Guide, 24 Row
8 GD3623 1 Adapter, 2" Male NPT To Cam Lock
9 GD3951 1 Dust Cap, 2" Cam Lock
10 GD11123 4 Anchor
11 GD15605 2 Band (3 Per Tank)
12 GD20111 1 Hose Bracket
13 GD25235
GD25499 4
-
U-Bolt, 8" x 12" x ¾"-10, 16 Row
U-Bolt, 8" x 16" x ¾"-10, 24 Row
14 G11496
GD26816 1
-
Adapter, 1½" Male NPT x 2" Flange, 16 Row
2" Flange x 2" Male Thread, 24 Row
15 G4304-02 1 Clear Plastic Tube, ½" x 33"
16 G10673 2 Hose Clamp, No. 8
17 GD26982 1 Fertilizer Tube Support Plate
18 GD26472 2 2" x 2", 90° Full Port Flange
19 GD26535 2 U-Bolt, 2½" x ⅜"-16
20 G4201-03 1 Hose, 2" x 18'
21 G4602-03 1 Black Helix Hose, 1¼" x 100'
22 G10001 4 Hex Head Cap Screw, ⅜"-16 x 1"
23 G10004 2 Hex Head Cap Screw, ⅜"-16 x 1¼"
24 G10096 1 Pipe Plug, ¾" NPT
25 G10108 6 Lock Nut, ⅜"-16
26 G10112 8 Lock Nut, ¾"-10
27 G10485 4 Hex Head Cap Screw, ⅜"-16 x 5"
28 G10626 1 Adapter, 1¼" NPT To Barb
29 G10628 1 Adapter, 2" NPT To Barb
30 G10674 2 Hose Clamp, No. 24
31 G10676 2 Hose Clamp, No. 36, Stainless Steel
32 G10901 4 Lock Nut W/Nylon Insert, ⅜"-16
33 G11091 4 Serrated Flange Nut, ⅜"-16
34 G11387 2 Flat Washer, ⅜" SAE
35 G11455 1 Reducer, 2" Flange x 1" Flange
36 G11457 2 Elbow, 2" Flange x 2" Hose Barb, 90°
37 GA8983 - Check Valve, Low Rate
38 G11467 2 Flange Clamp SS 50 Series
39 G11468 6 Flange Clamp SS 75 Series
TM
M0247-02 Model 4900
P209 Rev. 11/13
