Master Cylinder, 24 Row (Without Flip Axle)
ITEM PART NO. QTY. DESCRIPTION
1 A17665 1 Barrel (Non-Stock Item)
2 GA16081 1 Check Valve
3 G6408-08
GR1037 4 Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
4 *D12239 1 O-Ring, No. 016
5 G6801-06
GR1045 1 Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To O-Ring
O-Ring
6 G10932 2 Hex Socket Head Cap Screw, 5/16"-18 x 2", Grade 8
7 GD23226 1 Manifold Block
8 GA17668 1 ⅜ " Hydraulic Steel Tube
9 G6400-08
GR1037 2 Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
10 GA8882 1 Counter Balance Valve
11 GA17669 1 ½ " Hydraulic Steel Tube
12 GD27235 1 Nylon Lock Nut, 1"-14, Grade 8
13 *D12085 2 Ring
14 *D12086 1 Seal
15 *D12244 1 Seal
16 GD19261 1 Piston
17 *D12226 1 O-Ring, No. 120
18 *D12243 1 BU Ring
19 *D12242 1 O-Ring, No. 345
20 *D12253 1 U-Cup
21 GD25813 1 Head Gland
22 *D12200 1 Wiper, 1¾"
23 GD12104 1 Ring
24 GA17667 1 Rod
25 G10640 2 Grease Fitting, ¼"-28
A GA17664 - Hydraulic Cylinder Complete, 4½" x 11⅛" (Part Number Stamped on Barrel)
B GR2140 - Seal Kit, Includes: (3)O-Rings, (1)U-Cup, (1)Wiper, (1)BU Ring, (1)Piston Ring, (1)
Piston Seal, (1)Energizer Seal
C GR1517 - Seal Kit For Counter Balance Valve, Includes: (3) O-Rings, (3) BU Rings
*Item is part of seal kit, item can not be purchased individaully.
Model 4900 M0247-02
Rev. 2/14 P150
