Master Cylinder, 12 Row
ITEM PART NO. QTY. DESCRIPTION
1 A17613 1 Barrel (Non-Stock Item)
2 GA16081 1 Check Valve
3 *D12239 1 O-Ring, No. 016
4 G6408-08
GR1037 4
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
5 G6801-06
GR1045 1
-
Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To O-Ring
O-Ring
6 G10932 2 Hex Socket Head Cap Screw, 5/16"-18 x 2", Grade 8
7 GD23226 1 Manifold Block
8 GA17627 1 ⅜ " Hydraulic Steel Tube
9 G6400-08
GR1037 2
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
10 GA17628 1 ½ " Hydraulic Steel Tube
11 GA8882 1 Counter Balance Valve
12 GD27235 1 Nylon Lock Nut, 1"-14, Grade 8
13 *D12050 2 Piston Ring, 3"
14 *D12051 1 Piston Seal, 3"
15 *D12209 1 Energizer Seal, 3"
16 GD25769 1 Piston
17 *D26582 1 O-Ring, No. 210
18 *D12202 1 O-Ring, No. 334
19 *D12203 1 BU Ring
20 *D19250 1 U-Cup
21 GD26466 1 Head Gland
22 *D19251 1 Wiper
23 *D19662 1 Ring
24 GA17626 1 Rod
25 G10640 1 Grease Fitting, ¼"-28
A GA17612 - Hydraulic Cylinder Complete, 3" x 13½" (Part Number Stamped on Barrel)
B GR2145 - Seal Kit, Includes: (1)Energizer Seal, (1)BU Ring, (3)O-Rings, (1)Piston Seal, (1)
Piston Ring, (1)Loaded U-Cup, (1)Wiper, (1)Ring
C GR1517 - Seal Kit For Counter Balance Valve, Includes: (3) O-Rings, (3) BU Rings
*Item is part of seal kit, item can not be purchased individaully.
