Kinze 4900 Front Folding Planter Rev. 3/14 User Manual
Page 9
ITEM
PART NO.
QTY.
(Per Row)
DESCRIPTION
1
G10229
2
Lock Washer, ⅜"
2
G10001
2
Hex Head Cap Screw, ⅜"-16 x 1"
3
G11123
10
Hex Serrated Flange Cap Screw, ⅜"-16 x ¾"
4
GA18535
1
Hopper Support
5
GD26972
2
Hopper Mount
6
GA2007
1
Hopper Hold Down Latch
7
G10309
2
Carriage Bolt, ¼"-20 x ⅝", Grade 5
8
G10621
2
Serrated Flange Nut, ¼"-20
9
G10809
1
Hex Head Cap Screw, ⅜"-16 x 3¼"
10
GD25380
1
R.H. Front Mounting Bracket
11
G10312
8
Carriage Bolt, 5/16"-18 x ¾"
12
G10620
10
Serrated Flange Nut, 5/16"-18
13
G10302
2
Carriage Bolt, 5/16"-18 x ⅞"
14
GD25379
1
L.H. Front Mounting Bracket
15
GD25384
1
R.H. Mounting Bracket
16
GD25383
1
L.H. Mounting Bracket
17
G10108
1
Lock Nut, ⅜"-16
18
GA18351
1
Position Switch Mount
19
GA18353
1
Position Switch Magnetic Reed
20
G11345
2
Phillips Pan Head Machine Screw, ¼” x ½”, Grade 2
A
GA18352
-
Position Switch Assembly (Items 18-20)
Hopper Support and Position Switch
Model 4900
M0247-02
Rev. 2/14
P6
TM
