ITEM PART NO. QTY. DESCRIPTION
1 GA17255
GA17256
GA17359
GA17360 1
-
-
-
L.H. Wing, 16 Row (Shown)
R.H. Wing, 16 Row
L.H. Wing, 12 Row
R.H. Wing, 12 Row
2 GA17263 4 Slave Cylinder Pin
3 GA17330
GA17670 2
-
See “Slave Cylinder, 16 Row” on page P139
See “Slave Cylinder, 12 Row” on page P137
4 GA17583 1 Adjustable Hook
5 G10640 4 Grease Fitting, ¼"-28
6 --- - ---
7 GD21759-10 2 Pin, 1¼" x 3.95"
8 GD21759-11 2 Pin, 1¼" x 12.64"
9 G11389 7 Flat Washer, ½" Plated SAE
10 G10111 4 Lock Nut, ½"-13
11 G11593 8 External Spiral Retaining Ring, 1¼"
12 G10016 4 Hex Head Cap Screw, ½"-13 x 2"
13 G10581 3 Hex Head Cap Screw, ½"-13 x 2¼"
14 G10071 3 Serrated Flange Nut, ½"-13
15 GA17254 2 Wing Wheel Module
16 GA17759 2 See “Wing Wheel and Hub Assembly, 12 Row and 16 Row” on page P115
17 GA4377 2 See “Wing Wheel and Hub Assembly, 12 Row and 16 Row” on page P115
18 GR0270 12 Lug Bolt, 9/16"-18
19 G10026 4 Hex Head Cap Screw, ¾"-10 x 2"
20 G10231 4 Lock Washer, ¾"
21 G11345 8 Phillips Pan Head Machine Screw, ¼" x ½", Grade 2
22 GD27188
GD27189 2
-
Harness Rail Cover, 12 Row
Harness Rail Cover, 16 Row
23 GD25639 16 T-Slot Nut
24 G10104 8 Hex Nut, ⅝"-11
25 G10230 8 Lock Washer, ⅝"
26 GA19000
GA19001 2
-
Aluminum Rail, 62", 12 Row
Aluminum Rail, 98", 16 Row
27 GD26082 4 Multi-Purpose Bracket
28 GB0772 8 Wire Clip
29 GB0773 8 Wire Support
30 G11389 8 Flat Washer, ½" Plated SAE
31 G10228 8 Lock Washer, ½"
32 G10014 8 Hex Head Cap Screw, ½"-13 x 1"
33 GD1114 4 U-Bolt, 7" x 7" x ⅝"-11
Wing Assembly, 12 Row and 16 Row
Model 4900 M0247-02
Rev. 11/13 P86
