Piston Pump with Manifolds, 12 Row and 16 Row Bulkfill
ITEM PART NO. QTY. DESCRIPTION
1 GA18327 2 Fertilizer Tube Mount
2 GD26344 2 Fertilizer Tube Mount Bracket
3 GA18163 2 Fertilizer Support
4 *GA18335
*GA18329 1
1 Fertilizer Manifold Assembly, 41", 12 Row
Fertilizer Manifold Assembly, 49", 16 Row
5 *GA18337
*GA18330 2
2 Fertilizer Manifold Assembly, 21⅝", 12 Row
Fertilizer Manifold Assembly, 20⅜", 16 Row
6 *GA18338
*GA18331 2
2 Fertilizer Manifold Assembly, 41¼", 12 Row
Fertilizer Manifold Assembly, 72¾", 16 Row
7 GD26274 10 U-Bolt, 1½" x ¼"-20
8 G10110 24 Lock Nut, ¼"-20, Grade B
9 G10674 16 Hose Clamp, No. 24
10 GD28835 - Clear Blue Tube, ⅜" O.D., 150'
11 GD6291 12 Insulated Clamp, ⅜"
12 GD17141 12 Connector, ¼" Male NPT
13 G11458 5 Adapter 1” Flange x 1¼" Hose Barb
14 G11498 11 Gasket, Flange Ribbed 1"
15 GA18590 1 Fertilizer Tee Mount
16 GD11721 2 U-Bolt, 5" x 7" x ½"-13
17 G10102 4 Hex Nut, ½"-13
18 G10228 4 Lock Washer, ½"
19 *GA18589 1 Center Fertilizer Manifold Assembly
20 GD26672 2 U-Bolt, 2" Diameter, ¼"-20
21 G11574 2 1" Manifold Coupling, 90°
22 G11467 11 Flange Clamp SS 50 Series
23 GA18875 1 Piston Pump Mount
24 G10001 2 Hex Head Cap Screw, ⅜"-16 x 1"
25 G10014 2 Hex Head Cap Screw, ½"-13 x 1"
26 G11091 2 Serrated Flange Nut, ⅜"-16
27 G10071 6 Serrated Flange Nut, ½"-13
28 GD15532 1 Bronze Bushing, ⅜ x ½"
29 GA11287 1 Double Idler Assembly
30 G11387 1 Flat Washer, ⅜" SAE
31 G10108 1 Lock Nut, ⅜"-16
32 G10306 1 Carriage Bolt, ⅜"-16 x 2"
33 G10552 1 Clevis Pin, ⅜" x 2"
34 G10860 2 Retaining Ring, ⅜"
35 GD5857 1 Spring
36 G10870 1 Clevis Pin, ⅜" x 1"
37 GA12330 1 See "Liquid Fertilizer Piston Pump (Uses 18 Tooth Sprocket)" on page P239
38 --- 1 See "Center Ground Drive Assembly" on page P226
39 G10039 2 Hex Head Cap Screw, ½"-13 x 1¾"
40 G10038 2 Hex Head Cap Screw, ½"-13 x 3"
41 G3310-82
GR0912 1
-
Chain, No. 40, 82 Pitch Including Connector Link
Connector Link, No. 40
42 G11353 2 Elbow, 1½" NPT, 90˚
43 G11569 2 Adapter, 1" Flange x 1¼" Male NPT
44 GA16837 1 Pressure Relief Valve, 100 PSI
45 G11575 1 1" Flanged Straight Coupling
46 G11583 2 1" Flanged Manifold Tee
47 G4200-05 1 Hose, 1¼" x 50'
48 G10615 2 Reducing Bushing, 1½" Male NPT To 1¼" Female
* See "Fertilizer Manifold Parts" on page P237 for individual parts.
