Base Machine Electrical Schematic
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA19392
1
ISO Extension Cable
2
GA18712
1
Draw Bar Hitch Cable
3
GA19391
GA19390
GA19389
1
-
-
ISO DL 30 Cable, 12 Row
ISO DL 40 Cable, 16 Row
ISO DL 60 Cable, 24 Row
4
---
-
See “Light/Reflective Decal Brackets” on page P195
5
---
-
See “Light/Reflective Decal Brackets” on page P195
6
GA19397
1
Lights Cable
7
GA19412
GA19424
GA19417
1
-
-
ISO PLT Cable, 12 Row
ISO PLT Cable, 16 Row
ISO PLT Cable, 24 Row
8
GA19414
GA19416
GA19420
1
-
-
R.H. Auxiliary Cable, 12 Row
R.H. Auxiliary Cable, 16 Row
R.H. Auxiliary Cable, 24 Row
9
GA19413
GA19415
GA19418
1
-
-
L.H. Auxiliary Cable, 12 Row
L.H. Auxiliary Cable, 16 Row
L.H. Auxiliary Cable, 24 Row
10
---
-
See “Lift Valve Block (Located on Bottom of Valve Block on Wing)” on page P156
11
---
-
See “Hydraulic Valve Block on R.H. Wing” on page P157
See “Hydraulic Valve Block on L.H. Wing” on page P158
12
GA19425
Master Module Tech
Model 4900
M0247-02
Rev. 11/13
