Kinze 4900 Front Folding Planter Rev. 3/14 User Manual
Page 35
ITEM
PART NO.
QTY.
DESCRIPTION
1
GD15804
2
Mount
2
GA18975
GA18974
1
-
L.H. Side Manifold, 12 Row and 16 Row
R.H. Side Manifold, 12 Row and 16 Row
3
GD26697
-
Fan Gasket
4
GA17879
2
See “Vacuum Fan Assembly” on page P35
5
GA19018
2
Air Filter, ⅛" NPT
6
GD27094
2
Vertical Mounting Fan Exhaust Diffuser
7
GD27181
2
Fan Diffuser Gasket
8
G10305
12
Carriage Bolt, ⅜"-16 x 1"
9
G10108
12
Lock Nut, ⅜"-16
10
G10111
8
Lock Nut, ½"-13
11
G10037
8
Hex Head Cap Screw, ½"-13 X 1¼"
12
GA14805
-
Air Pressure/Vacuum Sensor
13
GA10765
GR1777
2
-
Analog Vacuum Gauge W/Hose Barb
Hose Barb, 3/16" x ⅛" NPT
14
GA10799
2
Breather, ⅛" Male NPT
15
G11215
6
Hex Socket Head Cap Screw, No. 6-32 x ⅜", Grade 8
16
GD15849-02
1
Clear Plastic Tubing, 5/16" O.D. x 120"
Vacuum Fan and Manifold, 12 Row and 16 Row
Model 4900
M0247-02
Rev. 11/13
P32
TM
