Parallel Arms, Mounting Support Plate, and Quick Adjustable
Down Forces Springs Option
ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GD8249
GD21337 4
-
Standard Down Pressure Spring (Shown)
Heavy Duty Down Pressure Spring
2 GD1114 2 U-Bolt, 7" x 7" x ⅝"-11
3 G10230 4-8 Lock Washer, ⅝"
4 G10104 4-8 Hex Nut, ⅝"-11
5 G10007 4 Hex Head Cap Screw, ⅝"-11 x 1½"
6 GA17660 4 T-Bolt, ⅝"-11 x 1½"
7 GD25068 1 Row Unit Support
8 GB0218 8 Bushing, 21/32" I.D. x ⅞" O.D. x 19/32" Long
9 G11391 8 Flat Washer, ⅝" SAE
10 GD28420 8 Hex Head Cap Screw, ⅝"-11 x 1¾", Grade 5
11 --- - See “Shank Assembly, Seed Tube, and Depth Adjustment” on page P1
12 GD25069 1 Lower Parallel Arm
13 GD25070 2 Upper Parallel Arm
14 GB0186 2 Spring Anchor
15 GD14217 2 Tab Lock Pin, 7/16" x 1½"
Model 4900 M0247-02
Rev. 11/13 P4
