Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 29)

ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 GA19426 1 Driver Module Motor
2 GD23591 1 Motor Module Mount Plate
3 GD2423 1 Funnel
4 GD2947 1 Hose, 7/16" x 28"
5 GA7270
GA6906
G10757
G10758
G10864 1
1
2
2
1 Bander Assembly
Granular Chemical Bander
Pan Head Screw No. 10-32 x 1¼"
Hex Nut, No. 10-32
Uni-Clamp
6 GA18050 1 In-Furrow Bracket
7 G11385 2 Flat Washer, ¼" SAE
8 G10110 2 Lock Nut, ¼"-20, Grade B
9 G10523 2 Slotted Pan Head Self-Tapping Screw, No. 10 x ½"
10 G11209 1 Wire Hose Clamp, ¾"
11 G10227 1 Lock Washer, ¼"
12 G11471 1 Phillips Pan Head Machine Screw, ¼"-20 x 1¾"
13 G10103 1 Hex Nut, ¼"-20
14 G10309 4 Carriage Bolt, ¼"-20 x ⅝", Grade 5
15 G10621 4 Serrated Flange Nut, ¼"-20
16 --- - See "Row Unit Electric Drive Electical Schematic" on page P188
17 --- - See "Row Unit Electric Drive Electical Schematic" on page P188
18 --- - See "Row Unit Electric Drive Electical Schematic" on page P188
19 GD26803 1 Bracket
20 GD26804 1 Bander Spacer
21 G10099 1 Cotter Pin, 3/32" x ½"
22 GD26572 1 U-Bolt, 1⅜" x ¼"-20
23 --- 1 See "Granular Chemical Hopper" on page P27
24 G10312 6 Carriage Bolt, 5/16"-18 x ¾"
25 G10620 8 Serrated Flange Nut, 5/16"-18
26 G10670 2 Hair Pin Clip, No. 3
27 GA18536 1 Granular Chemical Hopper Support (Sub Order Code 700-01213)
28 G10171 2 Hex Head Cap Screw, 5/16"-18 x 1¼"
29 G11386 4 Flat Washer, 5/16" SAE
30 GD26918 - Hanger Bracket, R.H.
31 G10310
G10227
G10103 4
4
4 Carriage Bolt, ¼"-20 x ¾", Grade 2
Lock Washer, ¼"
Hex Nut, ¼"-20
32 GD1116 - Hanger
33 GD2947 1 Hose, 7/16" x 28"
34 GA2075 - Diffuser, 14" Band
35 G10306
G10229
G10101 1
1
1 Carriage Bolt, ⅜"-16 x 2"
Lock Washer, ⅜"
Hex Nut, ⅜"-16
36 GD1118 - Clamp
37 G10452 - Cotter Pin, ⅛" x ½"
38 GD26919 1 Hanger Bracket, L.H.
Granular Chemical Rear Banding Options and Meter
(Electrical Drive)
Model 4900 M0247-02
Rev. 11/13 P26
