Kinze 4900 Front Folding Planter Rev. 3/14 - Manual (Page 91)

Wing Assembly, 24 Row
ITEM PART NO. QTY. DESCRIPTION
1 GA18473
GA18472 1
-
L.H. Wing, 60'
R.H. Wing, 60'
2 GA18901 2 See “H-Frame Wheel and Hub Assembly, 16 Row and 24 Row Wing Wheel and Hub
Assembly, 24 Row” on page P114
3 GA18898 2 Wing Wheel Module
4 GA17583 1 Adjustable Hook
5 GA17765 2 See “H-Frame Wheel and Hub Assembly, 16 Row and 24 Row Wing Wheel and Hub
Assembly, 24 Row” on page P114
6 GD27087-02 2 Pin, 1.48” x 14¼"
7 G10640 4 Grease Fitting, ¼"-28
8 GD24433 1 Vacuum Mount Cap (Not Used W/Vacuum Meters)
9 G10001 8 Hex Head Cap Screw, ⅜"-16 x 1" (Not Used W/Vacuum Meters)
10 G10071 3 Serrated Flange Nut, ½"-13
11 G10330 4 Lock Washer, ⅞"
12 G10362 4 Cotter Pin, ¼" x 3"
13 G11389 3 Flat Washer, ½" Plated SAE
14 G10448 4 Hex Head Cap Screw, ⅞-9 x 2½", Grade 8
15 G10581 3 Hex Head Cap Screw, ½"-13 x 2¼"
16 G10622 8 Serrated Flange Nut, ⅜"-16 (Not Used W/Vacuum Meters)
17 GA19002 2 Aluminum Rail, 194"
18 GB0772 14 Wire Clip
19 GB0773 14 Wire Support
20 GD25639 12 T-Slot Nut
21 G11345 16 Phillips Pan Head Machine Screw, ¼" x ½", Grade 2
22 G10228 8 Lock Washer, ½"
23 G11389 8 Flat Washer, ½" Plated SAE
24 G10014 8 Hex Head Cap Screw, ½"-13 x 1"
25 GD27189 4 Harness Rail Cover
